Shafts diameter mm. 30.
Rolls diameter mm. 138.
Geared motor HP 1.
Two forming rolls.
Shafts speed 9/18 RPM.
Steel frame.
Steel shafts in special steel.
Gear in special steel cut from solid stock.
Millimeter and decimal reading for pressing rollers adjustement.
Vertical and horizontal working position.



Shafts diameter mm. 30.
Rolls diameter mm. 138.
Geared motor HP 1.
Two forming rolls.
Shafts speed 9/18 RPM.
Steel frame.
Steel shafts in special steel.
Gear in special steel cut from solid stock.
Millimeter and decimal reading for pressing rollers adjustement.
Vertical and horizontal working position.
Dimension mm: base 665 x 740 - Height 1400.
Approximate weight : Kg 170.

Standard rolls - Lateral straghteners - Dual electric control pedal -
Service spanner - Instruction manual

Shafts diameter mm40.
Motor HP 2.
Shafts speed 10 RPM.
High resistance steel shafts rotating on double bearings.
Insert slide on hardened guides.
Steel frame.
Gear in special steel cut from solid stock.
Vertical and Horizontal working position.
Mechanical adjustment of the upper roll with readout of the decimal position by electronic digital display.



Shafts diameter mm50.
Motor HP 2.
Shafts speed 10 RPM.
High resistance steel shafts rotating on double bearings.
Insert slide on hardened guides.
Steel frame.
Gear in special steel cut from solid stock.
Vertical and Horizontal working position.
Mechanical adjustment of the upper roll with readout of the decimal position by electronic digital display.

Standard rolls - Lateral straghteners - Dual control pedal -
Service spanner - Instruction manual.
